Quick Details

  • Condition: New
  • CNC or Not: CNC
  • Place of Origin: Shandong, China (Mainland)
  • Brand Name: Multitech
  • Model Number: ITM1325AD
  • Voltage: 220/380V 50/60HZ
  • Power(W): 9.0KW
  • Dimension(L*W*H): 1300*2500*300mm
  • Weight: 1500kg
  • Certification: CE FDA
  • Warranty: 1.5 Years
  • After-sales Service Provided: Engineers available to service machinery overseas
  • Control system: Syntec control system
  • Application 1: woodoworking funiture
  • Motor: Yaskawa servo motor
  • Spindle: 9.0KW Italian HSD spindle
  • transmission: XY- helical gear transmission
  • Inverter: Taiwan Delta Inverter
  • Application: Furniture Processing ATC Cnc Router
  • Working table: vacuum table
  • Control: Synthec Control System
  • Name: cnc router machine with 10 tools auto tool change

Packaging & Delivery

Packaging Details: standard plywood case

Most popular cnc router machine with 10 tools                        auto tool change ITM1325AD







cnc router machine with 10 tools auto tool change application:





1. Woodworking industry: classic mahogany furniture products processing
2.

The advertising industry: advertising signs making,sign making, acrylic cutting,

plastic molding, a variety of materials of advertising decorative products making.

3. Other Industry: a variety of shadow carving, embossment, widely used in craft gifts industry
4.

It can also be applied to: aluminium board cutting industry, aluminum plate, aluminum-plastic panels, aluminum honeycomb panels, aluminium section, 3D ornamental engraving craft,

wave board production, various types of man-made plate opening and shaping, LED, neon shaped groove literal cutting, Light box molding.

Acrylic, copper board, PVC board, artificial stone, MDF board and other kinds of plates processing





cnc router machine with 10 tools auto tool change configuration :


Description

Parameter

X,Y Working Area

1300*2500mm

Z Working Area

300mm

Table Size

2150*4060mm

Resolution

0.01mm

Lathe Structure

Seamless welded steel structure, better than cast iron one

X,Y Structure

Rack and pinion, gear drive,

Taiwan Hiwin H30 square guide rails

Z Structure

Germany-made rolling ball screw,

Taiwan Hiwin H30 square guide rails

Max. Idling Speed

60m/min

Spindle

Italy HSD air-cooling 9.0 KW

Spindle Speed

0-24000r/min, variable speed

Working Voltage

AC380V/50Hz

Motor and driver

YASKAWA

Working Mode

Servo

Command

G code (HPGL,U00,mmg,plt)

Operating System

SYNTEC control system

Diameter of Cutter

φ3.175-φ12.7

Cooling Mode

Air-cooling

Dust-collect Function

Yes

Work Holding

By suction or clamp

Tool Magazine

Linear-style auto-tool changer system with 8 pieces of tools

Net Weight

2000KG









cnc router machine with 10 tools auto tool change pictures:







Features of cnc router machine with 10 tools auto tool change:



1. Linear style automated tool changer with 8 pieces of tools in total.
2.9.0KW (optional) Italy made air cooling spindle, very stable and durable.
3.

Vacuum table with 8 vacuum zones,

which can adsorb different size materials and has strong suction of 23 cube meters /hour.

4.Advanced syntec control system
5.Oil-injection system makes the maintenance more convenient.
6.

 Japan YASKAWA servo motor and driver, greater accuracy and stability.
















The sample cnc router machine with 10 tools auto tool change:























After sales of cnc router machine with 10 tools auto tool change:



1. warranty: 12 months
2.

provide technical services to the door(We have professional engineers to offer machine installation

 commissioning and maintenance)

3.  replace all parts for free during the warranty period(no human damage)
4. 24 th technology online support (skype,yahoo,MSN)





Company information



1. Multitech product is widely used in almost all the materials you can think of.
2. Multitechcompany is specialized in CNC Router and laser machine manufacturing and selling.
3.

Multitechmachine with high precision and excellent reputation is the most reliable product you can

 choose.

4.

 Multitechcompany has all kinds of machines in store, the delivery time is much shorter than other

companies.

5.

Multitechcompany has international technical service office and provides 24 hours online services

and technical supports for customers.

















Customers satisfaction is our pursuit:



 Anything I can do for you please let me know ,I will do my best to satisfy you .

 If you have any kind of question please make it easy to let me know,I am always ready

 to share things with you.Customers’ satisfaction is our pursuit.








Contact me all the time :

Anything I can do for you please let me know ,I will do my best to satisfy you .If you have any kind of question please make it easy to let me know,I am always ready to share things with you.Customers’ satisfaction is our pursuit.
